Rectangular Cooling Tower

TYPE
SCT-s
WATER
VOLUME
(1/min)
DIMENSION (mm) AXIAL FLOW FAN WEIGHT (kg.)
W L H DIAMETER
(mm)
MOTOR DRY OPERATION
HP QTY
100 1300 4050 1895 3125 1550 3 1 640 1957
125 1625 4050 1895 3525 1550 3 1 735 2157
150 1950 4300 2145 3525 1750 5 1 765 2197
175 2200 4300 2145 3875 1750 5 1 925 2627
200 2600 4750 2595 3875 2150 5 1 975 2737
225 2900 4750 2595 4225 2150 7.5 1 1135 3167
250 3000 4750 2595 4325 2150 10 1 1215 3367
300 3500 5250 3095 4375 2450 10 1 1485 3827
350 4200 5250 3595 4375 2450 15 1 1725 4547
400 4800 4750 5095 3875 2590 15 1 1935 5427
500 5400 4750 5095 4325 2590 20 1 2185 6307
